Series : Single point
Mounting Type : Fixed installation
Description : Single point, beehive sms load cell
Model Number : SC601
Type : Load Cell
Place of Origin : Guangdong, China
Brand Name : SNC
Use : weight measure, beehive scale
Theory : analogue sensor
Output : 2mv/v
Material : aluminum alloy load cell
Capacity : 3kg -120kg aluminum alloy load cell
Accuracy class : C3 / C2
rated output : 2.0±0.2mV/V
platform size : 250x350mm
application : table top scale, price scale, beehive scale
Operating Temperature : -10~+40 ℃
Size : 130 x 30 x20 mm
Voltage - Supply : 5-12VDC
Packaging : 100 units per carton
MOQ : 10 pieces
Price : $90-95/pieces
Features:
1, aluminum alloy, hermetically sealed with glue to IP65,
2, Surface anodized and anti-corrosion, integral structure and easy installation.
3, Application: electronic top scale, floor scale and other weighing equipment.
It uses 4-core shielded cable (φ4×420mm). The length of the cable is adjustable according to customer requirement.
Parameters:
Application | Price computing scale, table top scale |
Model | SC601 |
Capacity | 3kg, 5kg, 6kg, 10kg, 15kg, 20kg, 30kg, 40kg, 50kg, 60kg, 100kg, 120Kg |
rated output | 2.0±0.15mV/V |
Accuracy class | C2 |
maximum number of verification intervals | 2000Nmax |
Minimum loadcell cerification intervals | Emax/5000 Vmin |
Combined error | ≤±0.03% RO |
Creep | 0.003%RO/30min |
Temp. effect on sensitivity | 0.0016 %RO/℃ |
Temp.effect on zero | 0.003%RO/℃ |
Zero balance | ±1.0 %RO |
Input resistance | 402±6 ohm |
Output resistance | 350±3 ohm |
insulation resistance | 5000 MΩ(50V) |
Recommended excitation voltage | 10-15V |
Compensated temperature range | -10-+40℃ |
operating temperature range | -35-+80 ℃ |
safe overload | 150 %RO |
Ultimate overload | 200%RO |
loadcell material | Auuminum |
platform size | 250x350 mm |
Connecting cable | Φ4.2x350 mm |
Method of connecting wire | Red- input+, black- Input-. Green- Output+, White- output - |
Sensor and Control Co., Ltd. was founded in 2006, mainly engaged in Torque Sensor, Load Cell, Pressure Transducer, Strain Gauges and Weighing Indicators. Since establishment, we insist the guidelines of "Customer Oriented, Quality Focused, Professional Service "All products we supply are environment friendly and has passed RoHS test.
Sensorcon, in accordance with the principle of the introduction of advanced professional ultrasonic gas cleaning, clean Room patches, automatic temperature compensation and detection, high and low temperature testing and thermal experiments, laser welding and printing, CAD design, manufacturing and testing sensor test equipment and production technology ,manufacture all varieties of sensors, high precision, stable performance and also has antiseptic, waterproof, anti-explosion, anti-lightning, etc favored deeply by users.
1.How to place an order ?
Please provide us more details of what you want, such as: application, measurement range, output, accuracy, thread type, electric connector and other related parameters.
2.Does SNCoffer any discount ?
Yes, if you buy large QTY, please contact us, we will give you a big discount.
3.What terms of payment are available ?
We accept T/T, L/C, Trade assurance, Western Union, Paypal, etc.
4.When will you arrange the production ?
We will arrange the production immediately after receiving your payment.
5.How do you ensure good product quality ?
We have a complete quality control system, all of our products are fully checked by IQC, OQC departments
before shipping to our clients.
6.Do you have warranty ?
Yes, we provide 1 year warranty for most of our products. Some products we offer 15month to 24 months warranty.
![]() |
Fixed Installation Beehive Sms Load Cell for 3kg 5Kg 10Kg 20Kg 30Kg 40Kg 50Kg 60Kg 100Kg 120Kg Made of Aluminium Alloy Images |
